主な機能／特長
- Number of Channels 7ch Amp. 7.1ch Processing
- THX －
- DTS HD Master & High Res. Audio/ES/96/24/Discrete & Matrix6.1/ Neo:6/Express
- Dolby True HD/Digital Plus&EX/ Pro Logic IIz, IIx, II/Virtual Speaker/Headphone
- DSD (SA-CD)/Neural － / ○
- SRS －
- 電流帰還型回路 －
- Discrete Amplification ○
- 電源トランス EI
- D/Aコンバーター 192kHz/24-bit
- Digital Signal Processing ANALOG DEVICES: SHARC 32-bit
- Video Off (Pure Direct) ○
- ソース・ダイレクト ○
- Chassis Slimline, Steel
- Variable X-over ○
- Video Up-conversion Composite to HDMI, Component to HDMI
- Auto Calibration by MIC Audyssey MultEQ
- Satellite Radio Ready －
- AM/FM チューナー 1
- Bass Redirection ○
- Lip-sync (digital audio delay) ○
- Software Upgradable by Marantz Service Center
In Outputs
- HDMI In 4
- Component In 3
- S-Video In 0
- Composite In 3
- HDMI Out 1
- Component Out 1
- S-Video Out 0
- Composite Out 1
- Analog L&R In 6 (including Front mini jack input)
- Analog L&R Out 0
- Digital Optical In 2
- Digital Coaxial In 1
- Digital Optical Out 0
- Digital Coaxial Out 0
- その他 Front USB input: 1
- Pre-Amplifier Out Subwoofer: 1
- Main Amplifier In －
- Multi-Channel In －
- Multi-Room Audio Out －
- Multi-Room Video Out －
- Multi-Room Speaker Out －
- Speaker A/B Speaker A or B
- Networking －
- External control －
- DC Triggers －
- D-Bus Remote (RC-5) In/Out 1 / 1
- Flasher In/IR Receiver In/Emitter out 1 / 0 / 0
- Front Panel A/V Inputs USB/Mini Jack
- ヘッドフォン出力 1
- AC Outlets (Switched/Unswitched) － / －
主な仕様
- Power Output 50W (20Hz - 20kHz, 0.08% THD, 2ch driven) x7
- S/N Ratio 98dB (IHF-A weighted, Source Direct Mode)
- Freq. Response (Analog In) 10Hz - 100kHz (+/-3dB, Source Direct Mode)
- Freq. Response (Dig In) －
- Frequency Range 87.5 - 107.9MHz
- S/N Ratio (Mono/Stereo) 70/67 dB
- Frequency Range 520 - 1710kHz
- S/N Ratio －
- Video Freq. Response (Component) 5Hz - 60MHz (+0, -3dB)
- Video Freq. Response (Composit, S-Video) 5Hz - 10MHz (+1, -3dB)
- Signal to Noise －
一般
- Color Black
- Front Panel Aluminum/Glass-resinforced resin
- 付属リモコン Backlight, Learning and Precode System remote
- Power Requirement AC120V 60Hz
- 消費電力 250W (Standby: 0.2W)
- Dimensions W x H x D (Inchs) 17-3/8 x 4-3/16 x 14-1/2
