In Outputs
- External control 否
- D-Bus Remote (RC-5) In/Out 1 / 1
- AC Outlets (Switched/Unswitched) 0/0
产品规格
- THD 0.02% (20Hz – 20kHz, 2 channel driven, 8 ohms load)
- Input Sensitivity/Impeance PHONO:MM:2mV/47k ohms, LINE:200mV/20k ohms, Power Amp Direct In:1.6V/15k ohms
- 频率响应 5Hz – 100kHz ±3dB (CD, 1W, 8 ohms load)
- S/N Ratio PHONO:MM:87dB, LINE:106dB, POWER AND DIRECT IN:125dB
- Number of Channels 2
- Output Power 70W (8 ohms), 100W (4 ohms)
- HDAM HDAM-SA3
- Power Transformer Double-shielded Toroidal Transformer
- Current Feedback Amplifier
- Speaker Terminal Marantz Original Custom x2 pair
- Tone Control New Tri Tone Control (Bass: 50Hz, Mid: 900Hz, Treble: 15kHz)
- 直接来源
- Speaker A/B
常规信息
- Color Black
- Front Panel Aluminum/Glass-reinforced resin
- 远程控制 Marantz System Remote Controller
- Power Requirement AC 120V 60Hz
- Power Consumption 200W (Standby: 0.3W)
- Dimensions W x H x D (Inchs) 17 3/8 x 5 1/8 x 15
- Weight (lbs) 26.9 lbs
