特性
- Disc Capacity 1
- Playback Formats Disc: SA-CD(Stereo), CD, CD-R/RW(CD-DA/MP3/WMA), USB: MP3/WMA/WAV/AAC
- HDAM HDAM and HDAM-SA2
- Current Feedback Analog Stage 否
- Power Transformer Double-shielded large capacity Toroidal power transformer
- Zero-Impedance Plate
- Double Layerd Bottom Plates
- Audio DAC Cirrus Logic CS4398
- Display On/Off
- Selectable Filters 否
- SA-CD/CD Text 否 / 否
In Outputs
- Analog L&R Out Unbalanced: 1 (Gold Plated Machined Brass)
- 耳机输出 1 (with Level)
- Digital Out Coax: 1, Opt: 1
- Digital In Coax: 1, Opt: 1
- Other In/Out USB type A: 1(Front), USB type B: 1(Rear) / 否
- External control 否
- D-Bus Remote (RC-5) In/Out 1 / 1
产品规格
- Format 1-Bit DSD
- Sampling Frequency 2.8224MHz
- 动态范围 110 dB (Audible range)
- 频率响应 2 Hz – 50 kHz (–3 dB)
- THD 0.001 % (1 kHz, Audible range)
- Format 16-Bit Linear PCM
- Sampling Frequency 0.002% (1kHz)
- 动态范围 44.1kHz
- 频率响应 100dB
- THD 2 Hz – 20 kHz
常规信息
- Color Black
- Front Panel Aluminum/Glass-reinforced resin
- 远程控制 Device Remote with Marantz Amp. Basic Control Function
- Power Requirement AC 120V 60Hz
- Power Consumption 25W (Standby: 0.3W or less)
- Dimensions W x H x D (Inchs) 17 3/8 x 4 5/16 x 13 9/16
- Weight (lbs) 17.2 lbs
