特性
- Disc Capacity 1
- Playback Formats Disc: SA-CD, CD, CD-R/RW(CD-DA/MP3/WMA, AAC), USB-A: MP3/WMA/WAV/AAC/iPod/iPhone/iPad, USB-B: PCM up to 192kHz/24bit, DSD 2.8 & 5.6 Mhz
- HDAM HDAM + HDAM-SA2
- Current Feedback Analog Stage 否
- Power Transformer Toroidal
- Zero-Impedance Plate 否
- Double Layerd Bottom Plates 否
- Audio DAC Cirrus Logic CS4398
- Display On/Off 否
- Selectable Filters 否
- SA-CD/CD Text 否
In Outputs
- Analog L&R Out 1 (Variable/Fixed Selectable)
- 耳机输出 1 (with Level)
- Digital Out Coax: 1, Opt: 1
- Digital In Coax: 1, Opt: 1
- Other In/Out USB-A: 1(Front), USB-B: 1(Rear)
- External control 否
- D-Bus Remote (RC-5) In/Out 1 / 1
产品规格
- Format 1-Bit DSD
- Sampling Frequency 2.8224MHz
- 动态范围 106 dB (Audible range)
- 频率响应 2 Hz – 60 kHz (–3 dB)
- THD 0.0012 % (1 kHz, Audible range)
- Format 否
- THD 0.0018 % (1 kHz)
- Sampling Frequency 44.1kHz
- 动态范围 101dB
- 频率响应 2 Hz – 20 kHz (±0.5 dB)
常规信息
- Color Black
- Front Panel Aluminum/Glass-reinforced resin
- 远程控制 Device Remote with Marantz Amp. Basic Control Function
- Power Requirement AC 120V 60Hz
- Power Consumption 29W (Standby: 0.2W)
- Dimensions W x H x D (Inchs) 17.3" x 4.2" x 13.43"
- Weight (lbs) 17.64 lbs
